KT5500 5-
1
/
2
” Tong & CLInCHER® BaCKup
SECTIon ConTEnTS
5.11
TECHnICaL ManuaL
pInIon aSSEMBLy
Item Type Description Qty Part Number
A Part GreaseFitting,1/8”NPTx90Degree 4 02-0093
B Part 1/2”UNCx1-1/4”HexBolt 8 09-1168
C Part 1/2”LockWasher 8 09-5110
D Part PinionBearingCap 2 997-D15-89
E Part PinionBearingSpacer 2 1400-89A
F Part PinionIdlerBearing 2 02-0007
G Part LowPinionGear 1 997-A5-88
H Part PinionGear 1 997-A7-86
J Part HighPinionGear 1 997-A4-87
