Festo CPX-CMAX-C1-1 Mounting, Installation And Diagnostics

2. Fitting and pneumatic installation
2−15
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
Mass moment of inertia for semi−rotary drives
Permissible mass moments of inertia for the DSMI swivel
module in electronically regulated operation with the CMAX
are shown in the following table:
Swivel module
Permissible mass moment of inertia
[kgm
2
* 10
−4
]
DSMI−25−... 15 ... 300
DSMI−40−... 60 ... 1200
Tab.2/6:Permissible mass moment of inertia
Festo will support you in calculating the mass moment
of inertia with software for calculating 2nd−degree mass
moments of ine
rtia for various basic bodies and standard
parts from Festo (e.g. DSMI push−on flange).
è www.festo.com ˛ Downloads ˛ Download Area:
Software, drivers
and firmware ˛ Enter search term: mass
moment of inertia
Note
Natural vibrations of the load can lead to malfunctions.
· Fasten the load so that vibration is kept to a minimum.
· Avoid masses on long, flexible lever arms.
