2. Fitting and pneumatic installation
2−14
Festo P.BE−CPX−CMA X−SYS−EN en 0908N H
Mounting position Maximum load Minimum load
horizontal (á = 0°) m
max
= 32
2
* 6 * 0.008 = 49.15 kg 0.1 * m
max
= 4.92 kg
vertical (á = 90°) 0.33 * m
max
= 16.22 kg 0.1 * m
max
= 4.92 kg
diagonal (45°) (1 2/3 sin 45°) * m
max
= 25.98 kg 0.1 * m
max
= 4.92 kg
Tab.2/5: Load example
Instructions for coupling (piston rod drives)
If a coupling is required between the piston rod and the
guide:
· Check the backlash of the coupling.
The following applies here: Coupling backlash Ţ 0.05 mm
· Adjust the coupling backlash accordingly, if necessary.
If there is too much coupling backlash, this may cause:
Noise due to knocking on the coupling
Increased coupling wear
Worsened operating behaviour.
Make sure that the coupling backlash does not exceed
0.05 mm.
Mounting instructions
· Mount the load backlash−free, if necessary with a guide.
