2. Number of the external input is displayed.
3. Press [Unit] or [MR] until the preferred key function appears.
4. Press [Print/M+] to save and go to the next external input number.
5. Repeat the above step 2 ~ 4 until instrument returns to F32.
Setting procedures: -
1. Press [Print/M+].
2. Name of the report output port is displayed.
Note: - avoid assigning RS485 for report output purpose unless Machine ID (set in F18) is = blank.
3. Press [Unit] or [MR] until the preferred report output UART number appears and press [Print/M+].
4. Instrument displays report detail setting. 3 parameters are available: -
a. Off = None of the 12 below-mentioned report detail will be outputted. If Off is selected, instrument returns to F33. In this case,
output report contains only the following data: -
• Non-Resettable Transaction Memory Serial No.,
• Date of the individual transaction,
• Net Weight of the individual transaction,
• Tare weight of individual transaction,
• Gross weight of individual transaction.
b. All = All the 12 below-mentioned report detail will also be outputted. If All is selected, instrument returns to F33.
c. Custom = To customize which of the 12 below-mentioned report detail will be outputted.
Report detail & Parameters: -
oP. Code = Operator No.
oP. Mode = Operation Mode No.
id = Machine ID.
Group = Machine Group No.
Time = Time of the individual transaction
C Code = Customer Code.
C_dESC = Customer Description.
P Code = Product Code.
P_dESC = Product Description.
