01-ECMSI-NT002.Rev B40
Axendis 10013 Manual Triggers
No EFL
at end of open line! Do not
connect anything to the output of the last
point.
†
According to APSAD R7 or NF S 61-970
installation rules, category CR1
cable must be used for:
- from the ECS to the first point (on the outward and return
journey in the event of a looped detection circuit);
- when crossing areas outside the
surveillance domain.
Refer to the APSAD R7 rule or
the NF S 61-970 in force.
32 DM maximum on ''open'' BUS 128
DM maximum on ''looped'' BUS
Cable to be used for wiring DM 10013
1 pair 8/10 cablethrigid without screen (SYS1)
Type CR1 and C2 (flame retardant), see note below
Manual Triggers CP135
CONTROL AND SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR
RACK BOX
19
