Finsecur Baltic 512 TYPE A - Port 1 (BR16) or Port 2 (BR17) to PC; Port 1 (BR16) or Port 2 (BR17) to Printer

01-ECMSI-NT002.Rev B40
Port 1 (BR16) or port 2 (BR17) to PC
ECS terminal block BR16 or BR17
SubD/9-pin connector
female
1
6
9
5
Port 1 (BR16) or Port 2 (BR17) to printer
Example of cabling for a dot-matrix printer. Ref: LX300+ (EPSON)
ECS terminal block BR16 or BR17
SubD/25 pin connector
male
1
14
25
13
BALTIC 512 TYPE A WALL OR RACK BOX CONTROL AND SIGNALING EQUIPMENT 512 POINTS
34
RS232
RS232
ABC
ABC
RS232
RS232
AB CA BC
