Finsecur Baltic 512 TYPE A - HOCHIKI Detector Wiring (REF Base: YBN-R;6 (IS) )

01-
ECMSI-NT002.Rev B40
HOCHIKI
Detector Wiring (REF Base: YBN-R/6 (IS) )
This
wiring applies for the following
detector:
Fi-
AC
EN
54-18: 2005 Entry/exit device EN 54-17:
2005
Short-circuit isolator
→ Hochiki detector: DRD-
E;
→ maximum number of
detectors:
32;
→ maximum loop length: 1000
meters.
VS
CN NO
SYT1
C2 or CR1 8/10e cable with screen
Length:
1000 meters max.
screen
grounding
+S
+S
5
6
-S
- E
2
5
6
-S
- E
2
1
1
+ E
+ E
4
3
4
3
Screen
DOA
Sextant Detector Wiring
RETURN
BUS (loopback bus only)
FIRST
Sextant-
DOA
SECOND
Sextant-DOA
LAST
Sextant-DOA
DEPARTURE
BUS
Earthing
of the screen at ECS level. Ensure the continuity of
the
screen on the bus via terminal E (from the Bus start to the
last
detector and return of the Bus if looping back)
The use of collective AI is done by programming the Bus.
Wiring action indicators (Sextant-IA)
Cable
Sextant-
IA
1 pair 8/10etype C2
- +
- +
1 pair 8/10etype CCR1
Max
2 AI - Screen continuity to last AI
→ 8/10 cableeSYS1 C category C2 or CR1
→ Maximum
loop length: 1600 m
→ Maximum
number of Sextant-DOA: 128
CONTROL AND SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR RACK BOX
23
+
-
