Finsecur Baltic 512 TYPE A - Technical Characteristics

01-ECMSI-NT002.Rev B40
Technical characteristics
EEA EN 54-4
main source 230 Vac 50 Hz 0.16 A max
1 sealed 12 V 7 Ah maintenance-free lead-acid battery
(included)
Secondary source
DLD 11.5V±0.3V
Ripple rate ±10%
Maximum battery charge current 480mA ± 10%
0.887 Ohms ± 0.2 Ohms (battery fault detection
above this value (battery internal resistance fault))
Internal battery monitor resistor
Max charge voltage 13.4V±0.2V
Maximum output current Imaximum a 250mA
minimum current 0A
Battery end voltage 10.5V
Main source protection Fuse 160 mA time delay
Secondary source protection 1.6 A time-delay fuse
Charger protection Electronic protection
EAES EN 12101-10
Equipment class Class A
Environmental class Clean interior, low temperature
Switching time from main source to secondary
source
< 1µs
Fire detection circuit
Number of fire detection lines 8 open lines or 4 looped lines
Maximum stitches/loop 32 in open line or 128 in looped line
Maximum number of detection zones 512 detection areas
Maximum number of points 512 dots
Cable SYS1 - 1 pair 8/10th(without screen)
60 Ohms (measurement on the negative wire, between the go and return
cable)
Maximum impedance
Optional functions
Point faults (access level 1)
Total power loss (access level 1)
Addressed Points Out of Service (Access Level 2)
Condition Trial (access level 3)
Additional functions (access level 3)
Alarm contact Inverter 30 V max, 1 A max
Fault contact Inverter 30 V max, 1 A max
Programmable contact relay 1 Inverter 30 V max, 1 A max
Programmable contact relay 2 Inverter 30 V max, 1 A max
Output use 12 v programmable Maximum current 200mA
2 type reportsNotice-E ECS/CMSI maximum or
32Aviso-LCDECS/CMSI
Computer link report output
Card with 16 programmable relay outputs (B512-16R) Only in external card via O12C card
2 RS232/RS485 serial communication outputs Printer mode, ModBus, remote front panel, PC, CMSI
1 USB communication port For board programming
Autonomy 72 h (output not used)
Environmental condition
Hygrometry 93%
Temperature - 5°C to + 50°C
CONTROL AND SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR RACK BOX
