01-ECMSI-NT002.Rev B40
Technical data (alarm function)
Zone/function (alarm)
Type of function Evacuation by broadcast evacuation signal
Number of alarm zones 1
Number of functions (UGA) 1
Timeout Adjustable from 0 to 5 minutes
Remote control line (alarm)
Number of rows of sound diffusers 2
12 V (internal power supply)
Tension
24 or 48 V nominal (AES certified NF S 61-940 imperative or
EAES EN 12-101.10)
1 A/line (external power supply)
700 mA (for both lines internally powered)
Fluent
Number of sounders/line Depending on the current available (internal or external AES)
Wiring (alarm)
Type of cables 2 x 1.5 or 2.5 mm² type CR1-C1
According to the remote control voltage and
consumption on the remote control line
Cable length
See paragraph "wiring of sound diffuser lines"
Additional functions (alarm)
Auxiliary contact Inverter 30 V max, 1 A max.
†
All DACs that comply with the NFS61-938 standard and are suitable for remote control mode are connected to the CMSI.
All BAES compliant with NF C71-800 or NF C71-801 standards are connected to an output
contact the CMSI.
CONTROL AND SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR RACK BOX
37
