UGA/CMSI commands and signaling
3
UGA NF S 61-936
ORDER
EVACUATION
GENERAL
1
2
9
PROCESS
10
DAY BEFORE
RESTRAINT
EVACUATION
GENERAL
11
ALARM
DAY BEFORE
RESTRICTED BROADCASTERS
SOUND
DEFAULT DIFFUSERS
SOUND
OUT OF SERVICE OUT OF SERVICE
CONTACTS
AUXILIARY
GISC
12
NF S 61-934
NF S 61-935
17
BALANCE SHEET
SECURITY
BALANCE SHEET
13
19
DISTURBANCE
BALANCE SHEET SECURITY
4
DISTURBANCE
BALANCE SHEET SECURITY
14
DISTURBANCE
5
7
16
15
8
18
6
Description of UGA/CMSI commands
No. Designation Explanation Level
Used to stop the alarm process during the time delay preceding
the triggering of the general evacuation sound signal
1 Process acknowledgment 2
Prevents the activation of the general evacuation sound signal
after a fire detection
2 Restricted Standby 2
Allows you to start the general evacuation sound
signal manually
3 General evacuation 1
Allows to check if the functions with position control are in waiting
state and without fault
4 Balance sheet 1
Activates the corresponding safety function (without
delay)
5 Manual override (X3) 1
Selects the power input (AES or standard power for the
corresponding function.
6 Feed Selection exterior 3
Selects external AES for remote control of sound
diffusers (UGA function)
7 AES Selection 3
Selects the time delay, the on/off of the sound diffusers, the
on/off of the auxiliary contact and the shutdown of the UGA.
Selection of UGA
parameters
8 3
