01-ECMSI-NT002.Rev B40
Technical characteristics (safety functions)
Feed
main source 230 Vac, 50 Hz, 0.16 A max
Secondary source 1 maintenance-free lead-acid battery 12 V - 1.2 Ah (supplied
Zones/functions (lockout)
Compartmentalisation
Smoke extraction
Type of function
Number of safety zones 1
Maximum number of safety functions 3
Maximum number of actuated safety
devices (DAS)
96
Maximum number of terminal controlled
devices (DCT)
176
Remote control lines (safety)
Break or shunt with and without position control in 24 or 48 V
DAS management
Number of remote control lines 3
Tension 24 to 48 V (external power supply required)
Power limited to 55 W per line
5 if position control 55 W
without position control
Number of DAS/line
Wiring (safety)
→ CR1-C1, 1 pair 8/10thfor monitoring the start and end of
stroke contacts;
→ CR1-C1, 1 pair, 1.5 or 2.5 mm² for the remote control of
transmission DAS;
Type of cables
→ U100 RO2V, 1 pair, 1.5 or 2.5 mm² for remote control of
breakout DAS. Command and control cables must be
separated.
→ Depending on the remote control voltage and consumption on
the remote control channel;
→ see paragraph “wiring of the “break” remote control
lines (without position control)”;
→ 1000 m maximum for control lines
Cable length
Miscellaneous (safety)
External AES status information battery fault and mains fault
BALTIC 512 TYPE A WALL OR RACK BOX CONTROL AND SIGNALING EQUIPMENT 512 POINTS
36
