Finsecur Baltic 512 TYPE A - IR² Flame Detector (Ref: 016581) and Explosion-Proof IR² (Ref: 016511) Wiring

01-
ECMSI-NT002.Rev B40
IR²
flame detector (ref: 016581) and explosion-proof IR² (ref: 016511) wiring
Key
switch, to be
fitted
mode only
memorized (NC contact)
Flame
detector
1
+
+
-
EAE 24V
-
2
5
+
-
FIAT
Relay
Fire
6
7
AR
Relay
Default
8
24
VDC nominal
(if the detector is configured in
memorized mode,
cut the
power
supply to reset it, using
the
contact)
Flame
detector
1
+
-
2
5
6
Relay
Fire
RFL:
10 kOhms 1/4W 5%
AR
7
8
Relay
Default
RA: 1 kOhm 1/4W 5%
Features Cable to be used for flame detector wiring
• Power
supply: 14 to 30 V
• Nominal
voltage: 24 V
Power
supply EAE <-> flame detector: 1.5mm², type CR1
FIAT 212 (412) <-> flame detector: 8/10th, type C2 (non-propagating)
Maximum distance 1000 meters
BALTIC
512 TYPE A WALL OR RACK BOX CONTROL AND SIGNALING EQUIPMENT 512 POINTS
22
32 detectors max
RFL
