Finsecur Baltic 512 TYPE A - Flame Detectors Ref: TV 63

01-ECMSI-
NT002.Rev B40
Flame detectors
ref: TV 63
CONTROL AND
SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR RACK BOX
31
brown black red gold
Cable to be used for connecting the UV detector
Alarm Resistance (Ra) = 1 kOhms - 1/2W
1
Section(min.) Kind
1 pair - 8/10th without screen C2 (non-propagator)
Entrance 1
brown black orange gold
Section(min.) Kind
2 x 1.5mm² CR1 (fire resistant)
Entrance 2
2
End of Line Resistance (Rfl) = 10 k Ohms - 1/2W
Entrance 3 Entrance 4
1 detector per input max. of
the line (1000m)
1 detector per input max. of
the line (1000m)
Entry 5 Entry 6
R
To
Rfl
RTo
Rfl
Entry 7 Entry 8
V- V+ L+ L- T2 C2 T1 C1 V- V+ L+ L- T2 C2 T1 C1
EAE/AES-
24V
1
2
230VAC
+
(NFS 61940)
(EN54-4) Baltic512-030/a
Ditto other entries
(leave Rfl if not used)
