Finsecur Baltic 512 TYPE A - Testing the Manual Call Points

01-
ECMSI-NT002.Rev B40
Testing
manual call points
Stock Report If the signage
is different...
1.
Put the zones to be tested or the
entire ECS in “test” mode
The
yellow "test" indicator lights up
3. MAINTENANCE
3.1.
TEST POSITION
→ Check :
Ö
→ Yellow colored bands appear
on
the membrane;
that the
MD or its zone is in
“test” mode;
2.
Activate a manual trigger and wait
a few seconds.
→ the
red LED on the DM flashes;
Ö MD
wiring
→ the red “fire”
indicator of the ECS
lights up.
→ remove
the detector from its base and
check for the appearance of a
communication fault.
→ The
yellow bands disappear
from the membrane;
3.
Reset the DM
→ Use
the reset key.
→ the
red LED on the DM goes out.
4.
Repeat this operation on
all the DMs.
Between
each attempt, rearm the system and wait for it to go back to standby (red indicator on the DM and red "fire"
indicator on the ECS goes out).
†
At the end of these tests, return the ECS to "standby" mode.
General Evacuation Signal Test
For
this test, the ECS and the UGA/CMSI must be in “standby” mode.
Only
the green "power on" light is on.
The goal :check for each requested zone:
→ triggering
the alarm process;
→ the
activation of the associated safety functions.
Stock Report
If the signage
is
different...
→ The ECS red “fire” light comes on
and the panel
buzzer sounds continuously;
Check :
1.
Trigger an alarm on a zone
serving the alarm and/or
security zone.
→ the
red "safety" LEDs of the safety functions
associated with the requested zone come on;
→ the wiring of the sound
diffusers;
→ At the end
of the PMU triggering time (adjustable from
0
to 5 min), the red “general evacuation” indicator light
comes on and the sounders emit the general
evacuation signal for 5 min.
→ the loop/UGA association;
→ the association loop/
CMSI
function.
2.
Check the absence of alarm
on the loop
Ö
Reset the MDs; Ö
ventilate
ADs.
→ The red "general evacuation" light
goes out;
→ the
sound diffusers stop.
3.
Reset the board
Ö
Enter level 2 code
(BBBB by default);
→ The red “fire” light goes out;
→ the
red “alarm” light goes out
Ö
to push on
"rearmament".
4.
Repeat this operation for each detection zone.
CONTROL
AND SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR RACK BOX
