Finsecur Baltic 512 TYPE A - Page 32

01-
ECMSI-NT002.Rev B40
Cabling
of the Aviso-E ECS/CMSI report
Features
→ 2 reports (ref: AVISO) max
→ Length:
1000m max
→ Cable type: 1 pair 8/10thmin (without screen)
→ Category
(cable): C2
Finsecur
Map: AVISO
ENTRANCE
+ BUS
-
BUS
Functioning
EXIT
+ BUS
-
BUS
→ Reference
to a report of information such as
• General
fire
• General fault
IIf the operating
report is outside the installation's
monitoring domain, use cable type: CR1.
Finsecur
Map: AVISO
ENTRANCE
+
BUS
-
BUS
EXIT
+ BUS
-
BUS
FI-
REP synthesis report wiring
MAIN
EQUIPMENT
AT
lim
U IT
- +
ALARM
CO NO NF
DER
ANGEME
NT
CO NO NF
+ +
2 pairs 8/10th,
SYS1 (without screen)
+ -
AD
D1
+ -
AD
D1
Features
→ 2
reports (ref: FI-REP) max
→ Length:
1000m max
→ Cable
type: 1 pair 8/10thmin (without screen)
→ Category
(cable): C2
Functioning
→ Reference
to a report of information such as
• General
fire
• General
fault
BALTIC
512 TYPE A WALL OR RACK BOX CONTROL AND SIGNALING EQUIPMENT 512 POINTS
32
