01-ECMSI-NT002.Rev B40
UGA/CMSI signage
No. Designation Explanation
Steady on: restricted standby activated
(the general evacuation signal does not trigger on a fire alarm)
9 Restricted standby (yellow)
Steady on: general evacuation signal in progress
10 General evacuation (red)
On flashing: general evacuation signal completed. Auxiliary
contacts not reset.
Steady light: presence of a short-circuit or a line break on at
least one of the two lines of sound diffusers
11 Sound diffusers fault (yellow)
12 Sounders out of order (yellow) Steady on: the sound diffusers have been deactivated
Steady on: the auxiliary contacts linked to the sound diffusers have been put out
of service
13 Auxiliary contacts out of order (yellow)
→ Steady on for functions with position control: the controlled
DAS have reached their safety position
14 Security (red)
→ Steady on for functions without position control: the associated
DAS have been ordered
→ On flashing for functions with position control: the controlled DAS
have not all reached their safety position
→ Steady light: at least one link with the associated DAS (remote
control or control line) is faulty (break or short-circuit)
15 Fault (yellow)
→ Flashing on: the associated DAS (with position control) are not all in
standby position)
Steady on: the associated DAS are in standby position and no line
fault is present.
16 Balance sheet (green)
Note 1: lit while the review button is pressed
Note 2: valid only for functions with position control
Steady light: indicates reception by the UGA of the "fire alarm"
information from the ECS
17 Alarm (red)
Indicates the presence of voltage (fuses in good condition) on the remote
control lines
Indicator (X3) (red, visible hood
open)
18
Break: on standby
Transmit: flashes during command
19 Function naming space Used to indicate the name of the safety function
CONTROL AND SIGNALING EQUIPMENT 512 POINTS BALTIC 512 TYPE A WALL OR RACK BOX
39
