Configuring the s UGA power source
"Hardware" configuration of the type of AES Aim :
→ allow the type of AES used to be selected (internal or
external);
→ allow adjustment of the overload protection on the
sounder lines.
BR1
† The overload detection thresholds beyond which the UGA
will cut out the lines of sound diffusers are determined at the
configuration via software
configuration Baltic PC (internal or external AES).
times by the position of the knight and the
Selection Jumper
External AES
PMU Trigger Delay Configuration
Purpose: to set the trigger delay sound diffusers.
12345 8
Operation: following a fire alarm, the sounders are triggered
immediately (by default) or after an adjustable time delay of 1
to 5 minutes, for an evacuation period of 5 minutes.
WE
→ Only switches 1, 2, 3, 4 and 5 are used;
→ validate the delay by toggling the switch corresponding to
the chosen delay to the "ON" position.
• Example: switch n°1: 1 minute,
switch n°2: 2 minutes, etc.
Selection switches
† Sif several switches are validated, the UGA retains the
highest value. The switches configure the delay time.
Only the configuration via the software of
g the trigger mode: n.configuration Baltic PC rè
timed/immediate/none
Mode Setup e triggering of the UGA
Configuration via configuration softwareBaltic PC
Trigger mode
→ Timed (by default): the sounders will be activated after the
set time delay (see configuration of the UGA trigger
delay).
→ Immediate: the sounders will be activated as soon
as the associated zone goes into alarm.
→ None: Sounders will not be activated.
† SIf the sounders are powered by external AES,
select the box in this menu.
