Finsecur Baltic 512 TYPE A - Page 55

01-ECMSI-NT002.Rev B40
Finsecur Sextant-DVAF-C white flashes quantity
line length Internal AES External EAES 24V External EAES 48V
1 Hz HP configuration
Flash DIP 3 DIP 4
100m 6 20 32
HP 1Hz We We
500m 2 11 32
HP 0.5Hz We Off
Configuration LP 1 Hz
LP 1Hz Off We
100m 11 32 32
LP 0.5Hz Off Off
500m 4 23 32
HP configuration 0.5 Hz
100m 14 32 32
500m 5 25 32
Configuration LP 0.5 Hz
100m 16 32 32
500m 7 32 32
Finsecur Sextant-DVAF-CR Red Flashes quantity
line length Internal AES External EAES 24V External EAES 48V
1 Hz HP configuration
Flash DIP 3 DIP 4
100m 6 20 32
HP 1Hz We We
500m 3 14 32
HP 0.5Hz We Off
Configuration LP 1 Hz
LP 1Hz Off We
100m 12 32 32
LP 0.5Hz Off Off
500m 3 23 32
HP configuration 0.5 Hz
100m 12 32 32
500m 4 25 32
Configuration LP 0.5 Hz
100m 18 32 32
500m 6 32 32
