Vital Signs Simulator
Pre-Defined Simulations
11
Table 7. Pre-Defined Patient Simulations (cont.)
Simulation Name Parameter Pre-Set Value
Bradycardic
Wave Form NSR (Adult)
ECG Rate 30 BPM
Respiration Rate 15 brpm
Temperature 35.0 °C
IBP Channel 1 100/65 mmHg (Art)
IBP Channel 2 25/10 mmHg (PA)
NIBP 100/65 (77) mmHg
SpO
2
85 %
Ventricular Fibrillation
Wave Form Atrial Fibrillation (Coarse)
ECG Rate No BPM
Respiration Rate 70 brpm
Temperature 34.0 °C
IBP Channel 1 35/15 mmHg (Art)
IBP Channel 2 35/0 mmHg (LV)
NIBP 35/15 (22) mmHg
SpO
2
80 %
Asystole
Wave Form Asystole
ECG Rate 0 BPM
Respiration Rate 0 brpm
Temperature 33.0 °C
IBP Channel 1 0 mmHg
IBP Channel 2 0 mmHg
NIBP 0/0 mmHg
SpO
2
50 %
After you set one of the pre-defined simulations, you can change the parameters
of one or all of the vital signs. Changes are not kept in the Product. The pre-
defined simulation parameters cannot be changed through the front panel.
There are seven custom pre-defined simulations in the Product. To set a custom
simulation:
1. From the Home screen, push the More softkey.
2. Push the Custom softkey.
Four custom simulation names show above the first four softkeys. The names
are Custom1, Custom2, Custom3, and Custom4. To show the next three
names, push the More softkey.
3. Push the softkey for a custom pre-defined simulation.
All the vital sign simulation parameters are set to the values contained in the pre-
defined simulation.
You can customize the seven factory simulations and seven custom simulations
through the Ansur functionality.
