ProSim 8
Users Manual
10
Pre-Defined Simulations
The pre-defined simulations are set through the softkeys along the bottom of the
Home screen. See Figure 2. There are seven factory pre-defined simulations:
normal, hypertensive, hypotensive, tachycardic, bradycardic, heart attack, and
asystole. A More softkey shows on the display for more simulations. Table 7 lists
the parameter values for each pre-defined simulation.
Table 7. Pre-Defined Patient Simulations
Simulation Name Parameter Pre-Set Value
Normal
Wave Form NSR (Adult)
ECG Rate 60 BPM
Respiration Rate 20 brpm
Temperature 37.0 °C
IBP Channel 1 120/80 mmHg (Art)
IBP Channel 2 28/15 mmHg (PA)
NIBP 120/80 (93) mmHg
SpO
2
97 %
Hypertensive
Wave Form NSR (Adult)
ECG Rate 130 BPM
Respiration Rate 40 brpm
Temperature 37.0 °C
IBP Channel 1 200/150 mmHg (Art)
IBP Channel 2 45/25 mmHg (PA)
NIBP 200/150 (166) mmHg
SpO
2
94 %
Hypotensive
Wave Form NSR (Adult)
ECG Rate 40 BPM
Respiration Rate 15 brpm
Temperature 37.0 °C
IBP Channel 1 60/30 mmHg (Art)
IBP Channel 2 15/10 mmHg (PA)
NIBP 60/30 (40) mmHg
SpO
2
95 %
Tachycardia
Wave Form NSR (Adult)
ECG Rate 180 BPM
Respiration Rate 50 brpm
Temperature 40.0 °C
IBP Channel 1 80/50 mmHg (Art)
IBP Channel 2 25/10 mmHg (PA)
NIBP 80/50 (60) mmHg
SpO
2
88 %
