13 SETUP MENU
MIDI/REMOTE: OTHER PAGE
Controller assignments for various other functions of the FM9.
PARAMETER Description
Tempo Tap Provides the ability to tap the tempo using an external controller.
Learn more in Section 11: Tempo.
Tuner Use this to remotely enter or exit the Tuner. See Section 12: Tuner.
Tuner on Heel Down This causes a controller such as an expression pedal to automatically display the
tuner when the value of the controller is less than 5%. This allows the tuner to be
activated, for example, whenever a volume pedal is pulled all the way back.
Preset Inc/Dec
Preset Inc/Dec Start/Stop
These allow you to step up or down through a sequence of presets with pre-
dened start and end/wrap points. Preset mapping and offsets are ignored.
Don't confuse this with the Preset Inc/Dec function of the FM9's onboard
footswitches. These switches have their own settings and ignore this value,
which is used only for changing presets via MIDI.
Scene Select This assigns a controller for the selection of specic Scenes. The controller value
(NOT the CC number) determines which Scene is loaded:
0 = Scene 1 2 = Scene 3 4 = Scene 5 6 = Scene 7
1 = Scene 2 3 = Scene 4 5 = Scene 6 7 = Scene 8
The series continues, cycling through scenes 1–8 for values up to 127 (Scene 8).
For more, see "Selecting Scenes & Channels Remotely" on p. 52
Scene Increment
Scene Decrement
The Scene Increment and Decrement functions allow you to step up or down
through scenes. These functions are triggered by CC data values above 63.
Input 1,2,3 Volume
Output 1,2,3 Volume
These parameters allow you to globally control the levels of the corresponding
Input or Output blocks.
Output 1 Volume Increment,
Output 1 Volume Decrement,
Output 2 Volume Increment,
Output 2 Volume Decrement
These options provide a convenient way to permanently increase or decrease the
MAIN output volume for the Out 1 or Out 2 Blocks in the currently loaded preset.
Each time Volume Increment is triggered, the MAIN is increased by 1.0 dB and
the preset is saved. This is the same for Volume Decrement, except it decreases
volume.
IMPORTANT! Any unsaved changes such as altered effect parameters or
bypass states will also be stored when either of these functions is triggered!
These functions are designed for use with momentary footswitches set up to
send a CC# value of 127 for “ON” and 0 for “OFF.” Do not use an expression pedal
or you may change levels +/-20 dB with a single sweep!
