15 SPECIFICATIONS
USB AUDIO
Format: USB Audio Class 2.0 compliant
Channels: 8 input, 8 output
USB Audio Clock: 48 kHz xed
MIDI INTERFACE
Input Connector: (1) 5-pin DIN
Out/Thru Connector: (1) 5-pin DIN
MIDI Over USB YES
PEDAL INTERFACE
Connectors: (3) 1/4" TRS phone jack
Format: Pedal: 10–100 kΩ max or Switch: SPST, momentary or latching
FASLINK II INTERFACE
Connectors: (1) XLR-F
WARNING: Connect ONLY to the FASLINK II connector on a Fractal Audio FC controller
GENERAL
Finish:
Controls:
Display:
Dimensions:
Weight:
Input Voltage:
Power Consumption:
Powder-coated steel chassis
12 buttons, 9 knobs (6 with “push” functions)
800×480 high contrast color LCD
20.2” W. × 3.5” H. × 9.3” D.
51.3cm W. × 8.9cm H. × 23.7cm D.
11 lbs 15.8 oz (5.44 kg)
90–264 VAC, 47 – 63 Hz (universal input)
<40 W
Backup Battery Life: >10 years
Backup Battery Type: CR-2032
Ventilation: Onboard fan with side and bottom venting. WARNING: Do not block vent holes!
ENVIRONMENTAL
Operating Temperature: 32 to 122 °F (0 to 50 °C)
Storage Temperature: -22 to 167 °F (-30 to 70 °C)
Humidity: Max. 90% non-condensing
