REGISTER SUMMARY MC68332
D-38 USER’S MANUAL
Table D-7 MC68332 Module Address Map
(Assumes SIMCR MM = 1)
SIM
Access Address 15 8 7 0
S $FFFA00 MODULE CONFIGURATION (SIMCR)
S $FFFA02 FACTORY TEST (SIMTR)
S $FFFA04 CLOCK SYNTHESIZER CONTROL (SYNCR)
S $FFFA06 NOT USED RESET STATUS (RSR)
S $FFFA08 MODULE TEST E (SIMTRE)
S $FFFA0A NOT USED NOT USED
S $FFFA0C NOT USED NOT USED
S $FFFA0E NOT USED NOT USED
S/U $FFFA10 NOT USED PORTE DATA (PORTE0)
S/U $FFFA12 NOT USED PORTE DATA (PORTE1)
S/U $FFFA14 NOT USED PORTE DATA DIRECTION (DDRE)
S $FFFA16 NOT USED PORTE PIN ASSIGNMENT (PEPAR)
S/U $FFFA18 NOT USED PORTF DATA (PORTF0)
S/U $FFFA1A NOT USED PORTF DATA (PORTF1)
S/U $FFFA1C NOT USED PORTF DATA DIRECTION (DDRF)
S $FFFA1E NOT USED PORTF PIN ASSIGNMENT (PFPAR)
S $FFFA20 NOT USED SYSTEM PROTECTION CONTROL
(SYPCR)
S $FFFA22 PERIODIC INTERRUPT CONTROL (PICR)
S $FFFA24 PERIODIC INTERRUPT TIMING (PITR)
S $FFFA26 NOT USED SOFTWARE SERVICE (SWSR)
S $FFFA28 NOT USED NOT USED
S $FFFA2A NOT USED NOT USED
S $FFFA2C NOT USED NOT USED
S $FFFA2E NOT USED NOT USED
S $FFFA30 TEST MODULE MASTER SHIFT A (TSTMSRA)
S $FFFA32 TEST MODULE MASTER SHIFT B (TSTMSRB)
S $FFFA34 TEST MODULE SHIFT COUNT (TSTSC)
S $FFFA36 TEST MODULE REPETITION COUNTER (TSTRC)
S $FFFA38 TEST MODULE CONTROL (CREG)
S/U $FFFA3A TEST MODULE DISTRIBUTED (DREG)
$FFFA3C NOT USED NOT USED
$FFFA3E NOT USED NOT USED
S/U $FFFA40 NOT USED PORT C DATA (PORTC)
$FFFA42 NOT USED NOT USED
S $FFFA44 CHIP-SELECT PIN ASSIGNMENT (CSPAR0)
S $FFFA46 CHIP-SELECT PIN ASSIGNMENT (CSPAR1)
S $FFFA48 CHIP-SELECT BASE BOOT (CSBARBT)
S $FFFA4A CHIP-SELECT OPTION BOOT (CSORBT)
S $FFFA4C CHIP-SELECT BASE 0 (CSBAR0)
S $FFFA4E CHIP-SELECT OPTION 0 (CSOR0)
S $FFFA50 CHIP-SELECT BASE 1 (CSBAR1)
S $FFFA52 CHIP-SELECT OPTION 1 (CSOR1)
S $FFFA54 CHIP-SELECT BASE 2 (CSBAR2)
S $FFFA56 CHIP-SELECT OPTION 2 (CSOR2)
$FFFA58 CHIP-SELECT BASE 3 (CSBAR3)
