115
EN
Wire feed speed v
D
Wire speed - taken from the welding parameters
Unit m/min (ipm)
Setting range 1.0 - 25.0 (40 - 985)
The wire speed value can also be specified or changed in the Process mix parameters.
Arc length correction
is applied from the welding parameters
Setting range -10.0 - +10.0
The arc length correction value can also be specified or changed in the Process mix pa-
rameters.
For CMT mix:
Positive correction: Increase in the pulsed voltage for the PMC phase
longer reverse movement in the CMT phase (increases arc
length)
Negative correction: Reduction in the pulsed voltage for the PMC phase
shorter reverse movement in the CMT phase (reduces arc
length)
Pulse/Arc-force dynamic correction
is taken from the welding parameters
Setting range -10.0 - +10.0
The pulse/dynamic correction value can also be specified or changed in the Process mix
parameters.
For CMT mix:
Positive correction: Increase in the pulse energy (pulse current height, pulse current
width)
Reduction in the pulse frequency in the PMC phase
Negative correction: Reduction in the pulse energy (pulse current height, pulse cur-
rent width)
Increase in the pulse frequency in the PMC phase
Upper power time correction (3)
to set the length of the hot process phase in a mixed process
Setting range -10.0 - +10.0
Factory setting 0
