Connecting the mains cable
General If no mains cable is connected, a mains cable that is suitable for the connection voltage
must be fitted before commissioning.
A universal strain-relief device for cable diameters from 12 - 30 mm (0.47 - 1.18 in.) is fitted
to the power source.
Strain-relief devices for other cable cross-sections must be designed accordingly.
Stipulated mains
cables
* Cable type for USA / Canada: Extra-hard usage
** Power source without CE mark; not available in Europe
AWG = American wire gauge
Power source Mains voltage Cable cross-section
USA / Canada * Europe
TPS 320i /nc 3 x 400 V AWG 12 4 G 2.5
3 x 460 V AWG 14 4 G 2.5
TPS 320i /MV/nc 3 x 230 V AWG 10 4 G 4
3 x 460 V AWG 14 4 G 2.5
TPS 320i /600V/nc ** 3 x 575 V AWG 14 -
TPS 400i /nc 3 x 400 V AWG 10 4 G 4
3 x 460 V AWG 12 4 G 4
TPS 400i /MV/nc 3 x 230 V AWG 6 4 G 6
3 x 460 V AWG 10 4 G 4
TPS 400i /600V/nc ** 3 x 575 V AWG 12 -
TPS 500i /nc 3 x 400 V AWG 8 4 G 4
3 x 460 V AWG 10 4 G 4
TPS 500i /MV/nc 3 x 230 V AWG 6 4 G 10
3 x 460 V AWG 10 4 G 4
TPS 500i /600V/nc ** 3 x 575 V AWG 10 -
TPS 600i /nc 3 x 400 V AWG 6 4 G 10
3 x 460 V AWG 6 4 G 10
TPS 600i /600V/nc ** 3 x 575 V AWG 6 -
