Stapler Faults
585
Problem Solving
15
3
With grasping the lever of the booklet staple
cartridge, push the booklet staple cartridge
downward. Then, pull out the booklet staple
cartridge upward.
4
Push down the metal part of the staple
cartridge.
5
Remove the jammed staples (1), and return the
metal part pushed down in step 4 to its original
position (2).
6
Return the booklet staple cartridge to its
original position.
7
Slightly push the booklet staple cartridge
upward, and make sure that it clicks into place.
Note • Return the booklet staple cartridge until ( )
of the booklet staple cartridge is fitted in ( )
of the booklet unit.
Be careful in removing jammed staples.
To Next Page
