4.6 Printing on Non-Standard Size/Long-size Paper
63
Printing
4
3
Click [Custom Paper Size].
The [Custom Paper Size] dialog box appears.
4
Select a desired custom definition from the [Details] list box.
5
In [Settings for], specify the lengths of short and long edges.
You can either enter the values using the keys on the keyboard, or [ ] and [ ] on the dialog box.
The short edge cannot be longer than the long edge even if it is within the allowable range. Con-
versely, the long edge cannot be shorter than the short edge even if it is within the allowable range.
6
To assign a name to a paper size, check the [Name Paper Size] check-
box and then enter the name in the [Paper Name] text box.
You can enter up to 14 characters for the name.
7
If necessary, repeat steps 4-6 to define the paper size.
8
Click [OK].
9
Click [OK] on the [Configuration] tab.
3
5
6
4
To Next Page
