Fujitsu ESPRIMO C7xx User Manual

System expan sio ns
Installing/removing a Sm artCard reader (optional)
Operation of this module is not permitted in Taiwan.
In systems equipped with a SmartCard reader, access can be restricted to those
users wh o have a c orresponding SmartCard.
Installing the SmartCard reader
SmartCardr eader
► Open the casing (s ee "Open ing the casing", Page 34).
► Break out the web at the SmartCard opening on the fron t cover.
2
2
1
► Remove the drive cage (see "Remov ing
the drive cage" , Page 37)
► Slide the SmartCard reader into the
bay provided for it (1) and secure it
with the tw o screws (2).
► Make sure that the SmartCard reader
is also between the two bracke ts.
Otherwise, you will not be able to insert
the SmartCard from outside.
► Connect the cable for the SmartCard reader to the mainboard and the SmartCard
reader. Refer to the manua l for the mainboard.
► Install the drive cage again (see "
Installing the d rive cag e", Page 38).
► Close the casing (see "
Closing the casing", Page 35).
Removing the SmartCard reader
SmartCar
dreader
► Open the ca
sing (see "
Opening the casing", Page 34).
1
1
2
► Remove the drive cage (see "Remov ing
the drive cage" , Page 37)
► Disconn
ect the SmartCard connector
from the
mainboard. Refer to the
manual
for the mainboard.
► Loosen the screws (1).
► Pull th
e SmartCard rea der out of the bay (2).
► Install the drive cage a gain (see "
Install ing
the drive cage", Page 38
► Clos
e the casing (see "
Closing t he
casi
ng", Page 35).
