System expansions
Installing and removing a WLAN module (optional)
WLAN module
Operation of this module is not permitted in Taiwan.
You can also install a WLAN module for w ireless LAN ( Local Area Network)
in the bay of the folded-ope n drive cage.
Installing the W LAN module
► O pen the casing (see "Opening th e casing", Page 34).
► Remove the drive cage (see "
Removing the drive cage", Pa ge 37).
2
2
1
► Slid e the WLAN module carefully into the designated bay (1) a nd secure it with the two screws (2).
Make sure that you do n ot scra tch the antenna on the front opening of the drive cage.
► Connect th
eUSBcabletotheWLANmodule.
► Connect the USB cable of the WLAN module onto the corresponding connector
on the mainboard. Refe r to the manual for the mainboard.
► Install t
he drive cage again (see "
Installing the dr ive cage", Page 38).
► Close the casing (see "
Closing the casing", Page 35).
Details on using Wireless LAN can be foun d in the online help system
included with the Wireless LAN software.
46 Fujitsu
