System expan sio ns
1
► Slide the drive with the EasyChang e rails into the bay (1). Check that th e component side of
the drive faces downwards towards the base of the casing (with the drive cage closed).
► Connect the cables
at the drive and at the m ainboard. Make sure the polarity is correct.
► Fold the drive cage into the closed position again (see chapter "
Closing the drive ca ge", Page 48).
► Fit the casing cov
er back on to the casing (see Chapter "
Reattaching t he casing cover.", Page 37).
If necessary, y
ou must adjust the entry for th e drive accordingly in the BIOS Setup.
Fujitsu 53
