Item Specification
Wi-Fi For details, refer to Specifications of Wi-Fi (page
304).
Network protocol (wired LAN, Wi-Fi) IPv4 (*6), TCP, UDP, ICMP, DHCP, DNS
HTTP/HTTPS
Touch screen 4.3-inch TFT color touch screen
Pressure-sensitive
Contactless Smart Card Reader Communication mode
● Compliant with the ISO/IEC 14443 Type A/Type B
● Compliant with the ISO/IEC 18092
*1:Long page scanning supports documents with a length up to 5,588 mm (220 in.) when the resolution is set
to 200 dpi or lower.
*2:Up to three plastic cards can be loaded in the ADF paper chute (feeder).
*3:Note that this is the hardware limitation, and the software's processing time such as data transfer time is
added to the actual time of scanning.
*4:The capacity varies depending on the paper weight.
For details, refer to Documents for Scanning (page 79).
*5:Use the USB cable that is supplied.
When connecting the USB cable to a USB hub, make sure you connect it to a USB hub that is connected to
the USB port of a computer.
Connection with USB 3.1 Gen 1/USB 3.0/USB 2.0 requires the USB port and the hub to support USB 3.1 Gen
1/USB 3.0/USB 2.0.
Also note that the scanning speed slows down when USB 1.1 is used.
*6:IPv6 is not supported.
● Specifications of Wi-Fi
Item Specification
Observed standards IEEE802.11a
IEEE802.11b
IEEE802.11g
IEEE802.11n
IEEE802.11ac
Communication mode Infrastructure mode (*1)
Frequency 2.4 GHz band
5 GHz band (*2)
Channel 2.4 GHz band: 1 to 13 ch
5G Hz band: 36 to 60, 100 to 140, 149 to 165 ch (increments of 4 ch)
Appendix
304
