Removing and installing components
during servicing
Installing and removing memory
expansion
MemorymoduleMainmemoryRemovingmemorySystemexpan sionSystem expansion
If you are asked by the Hotline/Service Desk to r emove and insta ll the memory
expansion yourself, proceed as follows:
Please observe t he safety information in chapter "Important notes", Page 13.
When installing/removing memory modules, the battery must be removed from
the notebook and the notebook must not be connected to the power supply,
see "
Prep aring to remove com ponents", Page 105.
Only use m emory exp ansion modules that have been approved for your
notebook (see "
Technica l data", Page 120).
Never use force when installing or removing a m emory extension.
Make sure that foreign objects do not fall into the memory extension compartment.
You must open the service compartment to remove o r install a memory module. On some devices,
opening the compartment ma y expose other compon ents. These components should be removed
and replaced only by authorised specialists. Therefore, be sure to observe the following:
Individual components can become very hot during operation. Therefore, we
recommend th at you wait one hour af ter switching off the notebook before removing
or installing memory modules. Otherwise, there is a risk of suffering burns!
As some components are exposed that are s ensitive to static electricity, please take
note of chapte r "
Notes on installin g and removing boards and components", Page 104.
Removing a cover
1
1
2
► R emove the screws (1).
► Pull off th e cover from the notebook in the direction of the arrow (2).
106 Fujitsu Technology Solutions
