Working with the notebook
Connect the notebook to the port replicator
► D isconnect the mains adapter cable from the DC socket (DC IN) of the note book.
1
2
3
► Position the note book on the port replicator in such a way that the docking connector on the
underside of the notebook is aligned with the docking connect or of the port replicator as shown.
► Press down on t
he notebook’s rear co rners s o that it locks into position.
► C onnect the mains ad apter cable to the DC jack (DC IN) of the port replicator (1).
► C onnect the pow
er cab le to the mains adapter (2).
► Plug the power cable into the ma ins socket (3).
72 Fujitsu Technology Solutions
