Removing and installing components
during servicing
Attaching the cover
1
2
2
► Place the cover into position, following the direction of the arrow (1).
► Secure the cover with the screws (2).
► In stall the battery again (see "
Removing and installing the battery", Pag e 54).
► Turn the notebook the right way up again and place it on a flat surface.
► R econnect the cables that were previously disconnected.
Finishing component removal
After you have removed or changed the system components as you required, please
prepare your device for operation again as follows:
► In stall the battery again (see "
Installing a battery", Page 55).
► Turn the notebook the right way up again and place it on a flat surface.
► R econnect the cables that you disconn ected before.
108 Fujitsu Technology Solutions
