Working with the notebook
SIM card
A SIM Card (Subscriber Identity Module) is a chip card which is inserted in a mobile telephone or
notebook and, together with an i ntegra ted U M TS module, enables access to a mobile radio network.
When handling SIM cards, follow the instructions supplied by the provider.
Inserting the SIM card
► Prepare for insertion of the SIM card, see chapter "Preparing to remove compo nents", Page 105.
► Open the protective rubber c
over of the SIM card slot.
Do not pull on the SIM card loc
k! The lock could break off otherwise. Always
slide the lock in the direc
tion of the arrow as shown.
a
2
3
1
► Slide the SIM card lock (a) in the
direction of the arrow (1).
The clip (a) controls the p
ower supply for
the UMTS modu le. The UMTS
module is
switched o ff while the cl
ip is open.
► Slide the SIM card as shown into
slot (2) until it engages.
► Slide the SIM card lock (
a) in the
direction of the arrow (
3).
► Close the protective rubber cover of the SIM card slot.
► Complete the insertion process, see chapter "
Finishing component remova l", Page 108.
Fujitsu Technology Solutions 67
