Tech nical data
Rechargeable battery
You can find information on the batteries used in your device on the
Internet at "
http://ts.fujitsu.com/suppor t".
In addition to the main b attery, you can order an optional battery which is inserted in the module slot.
All rechargeable batteries are 6-cell batteries.
Main battery
Optional battery (to
be inserted in the
module bay)
Rated voltage 10.8 V 10.8 V
Rated capacity 62.6 Wh 41 Wh
Nominal pow er 5.800 mAh 3.800 mAh
The operating time depends on the d evice configuration, the active
applications and the energy-saving settings.
Mains adapter
The following technical data applies to the mains adapter supplied with the notebook
and to the mains adapter supplied with the port replicator which you can ord er optionally.
Primary
Rated voltage
100 V to 240 V (automa tic)
Rated frequency 50 Hz to 60 Hz (automatic)
Max. rated cu rrent 0.7 A to 1.2 A
Secondary
Nominal pow er 80 W
Rated voltage 19 V
Max. rated current 4.22 A
An additional mains adapter o r power cable c an be ordered at any time.
122 Fujitsu Technology Solutions
