Working with the notebook
Removing the card
Always remove the card according to the rules described below, to
ensure that none of your data is lost.
You can stop the c ard using the corresponding icon in the task bar:
► Le ft click on the icon to sa fely remove hard w are, located i n the taskbar.
► Select the card y ou want to stop
and rem ove.
► Press the "Ente r" key.
Wait for the dialog box which tel
ls you that it is now safe to remove the card.
1
2
► If the eject button is lowered, you must
first cause the eject button to release
from the notebook casing. To do this,
press the eject button until it pops out.
Press the eject button (1) so t hat the card
protrudes a little from the notebook.
► Pull the card out of the slot (
2).
► Insert the card placeholder into the
slot guide.
► Carefully slide the placeholder for the
card as far as it will g o into th e slot.
Do not use e xcessive force.
Loudspeakers and microphones
Microph
one
Loudspe
akers
Basslou
dspeaker (subwoofer)
Volum ec
ontrol
Information on the exact position of the speakers and m icrop hone can be
found in "
Ports and controls", Page 9 .
Please refer to chapter "
Key co mbinations", Page 45 for information on setting the volume
and also enabling/disabling the loudspeakers using key combinations.
If you attach an external microph one, the built-in microphone is disabled.
When you connect headphones or external speakers, the built-in speakers are disabled.
Information on connecting headphones and a microphone can be found
in "
Connecting external devices", Page 98.
66 Fujitsu Technology Solutions
