178 Upgrade and Maintenance Manual BX900 S2
Appendix
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-13668-001.fm
Front docking board
Figure 74: Front docking board
13.2 Configuration tables
13.2.1 Server blade / storage blade fitting rules
Please refer to chapter "Power supply" on page 85 and to the relevant server
blade and storage blade operating manuals.
13.2.2 Power supply unit / fan module fitting rules
Please refer to chapter "Power supply" on page 85.
Component Reference
Front docking board
"Replacing the front docking board" on
page 160
