BX900 S2 Upgrade and Maintenance Manual 161
Front docking board
11.2.3 Removing the front docking board
Figure 57: Removing the Local Service Display stop
Ê Loosen the Phillips screw (1) to remove the Local Service Display stop.
Figure 58: Unlocking the front docking board
Ê Press on the touch point (arrow) to unlock the front docking board. The touch
point engages in the unlocked position.
/
