Fujitsu PRIMERGY RX1330 M4

▶
"Switching on the server" on page 58
.
13.4.3 Replacing the front VGA board
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Locating the defective server" on page
43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Removing the front panel module" on page 269.
Removing the defective front VGA board
▶
Remove the front VGA board, see "Removing the front VGA board" on
page 275.
Installing the new front VGA board
▶
Install the front VGA board, see "Installing the front VGA board" on
page 273.
Concluding steps
▶
"Installing the front panel module" on page 271.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
Front panel
RX1330 M4 Upgrade and Maintenance Manual 277
