186
Chapter 7 Installing Internal Options
8 Turn the card locking frame over and align the connectors. Install the card
locking frame by pushing on the green "PUSH" sticker area, then tighten the
screws.
9 Attach the top cover and return the server back into the rack.
"7.2 Removing and Attaching the Top Cover" (pg.166)
■ How to Remove an Expansion Card
To remove an expansion card, simply reverse the "7.5 Installing Expansion Cards" (pg.179)
procedures.
Card locking frame port
Green stickers (PUSH)
To Next Page
