138
Chapter 6 Installing Internal Options
6.2.2 How to Remove the Fan Duct
1 Turn off the power and all peripheral devices, and pull the server out from the
rack to remove the top cover.
"6.2.1 How to Remove the Top Cover" (p.136)
2 Touch a metal part of the server to discharge static electricity.
3 Remove the fan duct.
Remove by inserting your finger into the release hole in the center of the fan duct.
How to attach the fan duct
To attach the fan duct, reverse the removing procedure.
Fun duct
Release hole
