Fujitsu Primergy RX300 S4 - 7.1 Switch Block Settings

182
Chapter 7 Configuring Hardware and Utilities
7.1 Switch Block Settings
This section explains the switch block settings for this server.
 Switch block location
The switch block is located on the baseboard as shown below.
 Switch block settings
The switch block settings are as follows:
table: Switch block settings
Switch
Number
Functions
Factory
Settings
Description
1
BIOS Recovery
Off
BIOS Recovery
2
Password Skip
Off
Clears the password that was set in the BIOS.
3
BIOS Write Protect
Off BIOS Write Protect
4
FDD Write Protect
Off
This switch is not used.
Switch block
[Rear]
[Front]
ON
OFF
4321
