136
Chapter 6 Installing Internal Options
6.2 Attaching/Removing Each Cover
When installing internal options, remove the top cover and fan duct. See below how
to remove each cover.
6.2.1 How to Remove the Top Cover
1 Open the rack door.
"1.4.1 Opening the Rack Door" (p.29)
2 Turn off the server and all peripheral devices. Also unplug all cables from the
server.
"1.4.3 Turning Off the Server" (p.32)
3 Loosen the screws that hold the server to the rack.
• Before attaching/removing the top cover and fan duct, turn off the server and
all peripheral devices. Also unplug all power cables from the server ("1.4.3
Turning Off the Server" (p.32)). Failure to do so may cause electric shock.
• Use stabilizers to prevent the rack from tipping when installing the rack.
Pulling the server out of the rack without installing stabilizers may cause the
rack to tip over.
To Next Page
