Fujitsu Primergy RX300 S4

140
Chapter 6 Installing Internal Options
6.3.2 Installable CPUs and Notes
 Installable CPUs
The following types of CPUs can be installed on this server. When installing an optional CPU, the two
CPUs must have the same product name (same frequency/cache size).
 Before installing an optional CPU, see "Appendix B.1 CPU" (p.246) to check the packaged product.
6.3.3 How to Install a CPU
1 Turn off the power and all peripheral devices, and pull the server out from the
rack to remove the top cover.
"6.2.1 How to Remove the Top Cover" (p.136)
2 Touch a metal part of the server to discharge static electricity.
3 Remove the fan duct.
"6.2.2 How to Remove the Fan Duct" (p.138)
4 Remove the socket protection cover by pulling the tab up.
table: List of Installable CPUs
Product name Product ID
Processor Xeon E5205 (1.86GHz)
PG-FG42G
Processor Xeon X5260 (3.33GHz) PG-FG42H
Processor Xeon X5270 (3.50GHz)
PG-FG42N
Processor Xeon E5405 (2GHz) PG-FG42J
Processor Xeon E5420 (2.50GHz) PG-FG42K
Processor Xeon X5460 (3.16GHz) PG-FG42L
Processor Xeon X5470 (3.33GHz)
PG-FG42M
Socket
protection cove
r
Tab
