PRIMERGY RX300 S4 User's Guide
6.8.2 Installable Power Supply Units
The following PSUs can be installed in this server.
6.8.3 How to Install the Power Supply Unit
This section explains how to install power supply units.
1 Turn off the server and all peripheral devices. Also unplug the power cable from
the inlet.
"1.4.3 Turning Off the Server" (p.32)
2 Remove the dummy unit.
Remove the screws on the dummy unit and pull it out by the handle.
 Store the removed screws in a safe place.
table: Installable PSUs
Product name Product ID
Power Supply Module
PG-PU125
• Areas around the PSU may remain extremely hot after shutdown. Wait for a
while after shutdown before removing the PSU.
Handle
[Rear]
