7.2.6 Peripheral Configuration Submenu
This submenu appears when selecting [Peripheral Configuration] from the [Advanced] menu.
Sets the serial port, parallel port, etc.
The items not listed in the figure below can be displayed using the scroll bar.
table: Items on the Peripheral Configuration Submenu
Item Setting Description
Serial 1 • Disabled
• Enabled
• Auto (Initial value)
• OS Controlled
Sets whether to enable or disable the serial port. Set
this to [Disabled] when used as a server
management port.
Note:
 When [Serial Multiplexer] is changed to
[iRMC], set this item to "Disabled".
Serial 1 Address 3F8h, IRQ 4
(Unchangeable)
Appears when [Enabled] is selected for [Serial 1].
Serial Multiplexer • System (Initial value)
•iRMC
Switches the function of serial port 1.
• System
Uses this port as a serial port. (Setting at the time
of UPS connection)
•iRMC
Uses this port as a server management port. In
this case, set [Serial 1] to [Disabled].
Serial 2 • Disabled (Initial value)
• Enabled
• Auto
• OS Controlled
Sets whether to enable or to disable the serial port.
Serial 2 Address 2F8h, IRQ 3
(Unchangeable)
Appears when [Enabled] is selected for [Serial 2].
Parallel • Disabled (Initial value)
• Enabled
• Auto
Sets whether to enable or to disable the parallel
port.
