Chapter 7 Configuring Hardware and Utilities
ATA Controller Config submenu
Sets the Serial ATA.
Parallel Mode Bidirection (Unchangeable) Sets the data transfer mode of the parallel port.
Appears when [Enabled] or [Auto] is selected for
[Parallel].
Parallel Address
• 378h,IRQ7 (Initial
value)
• 278h,IRQ5
•3Bch,IRQ7
Sets the parallel port address.
This item appears when [Enabled] is selected for
[Parallel].
USB Host Controller Enabled (Unchangeable) Sets whether or not to use the USB controller (2.0
or 1.1 standard).
USB 2.0 Host Controller Enabled (Unchangeable)
USB BIOS Supported
Devices
Auto (Unchangeable) Sets which type of USB device should be used in
BIOS.
USB Boot Delay 0 s. (Unchangeable) Sets the waiting time for booting from a USB
device.
USB BIOS Hot-Plug Enabled (Unchangeable) Allows Hot-Plug of the USB device used for BIOS.
USB Front
• Disabled
• Enabled (Initial value)
Sets whether or not to use the USB connector on the
front.
USB Rear
• Disabled
• Enabled (Initial value)
Sets whether or not to use the USB connector on the
back.
ATA Controller Config Configures additional settings.
"
ATA Controller Config submenu" (p.192)
Diskette Controller Disabled (Unchangeable) Sets whether or not to enable the floppy disk
controller.
Mouse Controller Auto Detect
(Unchangeable)
Sets whether or not to use the mouse connected to
the mouse port.
Onboard Video Enabled (Unchangeable) Sets whether or not to enable the onboard video
controller.
LAN Controller LAN 1 & 2 (Unchangeable) Sets whether or not to enable the onboard LAN
controller (LAN 1, or LAN 1 & 2).
LAN 1 Remote Boot • Disabled (Initial value)
•PXE
• iSCSI
Sets whether or not to load the OS from the server.
This function is especially used when both floppy
disk drive and hard disk drive are not installed, or
both powers are turned off.
LAN 2 Remote Boot
table: Items on the ATA Controller Config Submenu
Item Setting Description
S_ATA Mode Compatible
(Unchangeable)
Sets the Serial ATA mode.
Primary IDE Channel Enabled (Unchangeable)
Sets whether or not to enable the Primary IDE
Channel.
Secondary IDE Channel
Enabled (Unchangeable) Sets whether or not to enable the secondary IDE
Channel.
table: Items on the Peripheral Configuration Submenu
Item Setting Description
