252
Appendix
 Connecting the server to a PC
Connect the server to a PC using an RS-232C cross cable.
 Configuring the terminal software (PC)
Perform settings for the remote control function using terminal software on the PC.
 Port configuration
Configure the port on the PC as follows:
(Window example)
table: Port Settings
Item Contents
Bits per second 9600
Data bits 8
Parity Not applied
Stop bits 1
Flow control Not applied
Server (Rear)
PC (Rear)
RS-232C cross cable
Serial Port
Serial Port
