U41057-J19-Z146-1-76 July 2004 02–TX150S2–135
Removal/installation routines Conversion of the housing model
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k04
Conversion of the housing model
From floorstand model to rack model
Requirements
– conversion kit
S26361-F2618-L220
– floorstand model has been switched off
– power cords have been disconnected
– left side cover has been removed
– hard disk cover and cover of the accessible drives has been removed (they
are no longer needed for the rack model)
– for floorstand model with redundant power supply:
anti-tilt bracket has been removed
– front cover has been removed (is no longer needed for the rack model, the
conversion kit contains an other front cover)
Remove the right side cover and the top cover (one part together) as follows:
Ê Unscrew the two screws on the rear side.
